Lithium Ion Battery Cabinet Solar Energy Storage Battery System

The Lithium Ion Battery Cabinet Solar Energy Storage Battery System has the functions of Monitoring of Power,operation mode,total charge and discharge, and abnormal status for PV, BESS, load, and grid;Three operation modes are optional: self use, battery priority and mixed economy;Time-of-day tariff setting;Revenue calculation and revenue data analysis.

Model:30kW/60kWh
Rated Voltage: 614.4V
Rated Capacity:62.67kwh
Rated Power: 30KW
Battery: 680Kg
Inverter: 650Kg
Dimension:2XBattery: 600*800*1630mm
(Including wheels)
Inverter: 800*800*1900mm

Send Inquiry

Product Description

LiFePo4  51.2V 102Ah Lithium Ion Battery Cabinet Solar Energy Storage Battery System for Telecome Backup with 30Kw/60Kwh Inverter and EMS


Short Description:

The hybrid inverter of Smart Bee series ESS adopts a highly integrated design. It only needs to directly connect the PV, battery, load, and power grid to the corresponding interface to realize the effective work of the system. The system can access a maximum of 60kW PV, 75kWh batteries and 30kW loads. Special attention should be paid to the rated load connected to the Inverter must be less than 30kW, otherwise, when the system is converted from grid-connected mode to off-grid mode, the Inverter may be overloaded and stop working due to excessive load.


【Built In EMS】The Lithium Ion Battery Cabinet Solar Energy Storage Battery System has the functions of Monitoring of Power,operation mode,total charge and discharge, and abnormal status for PV, BESS, load, and grid;Three operation modes are optional: self use, battery priority and mixed economy;Time-of-day tariff setting;Revenue calculation and revenue data analysis.
【Grade A LiFePO4 Cells】LiFePO4 battery have exceptional quality since they are manufactured by Automotive Grade LiFePO4 Cells with higher energy density, more stable performance & greater power.
【Support Scale in Parallel】The High voltage battery system support Parallel connection for scalability, to achieve higher capacity.
【LCD Display Screen】The LCD Screen allows you to monitoring the battery performance in real time. The Real-time monitoring to take control of battery and avoid battery failure, collecting battery data to bring you maintainance convenience and confidence whenever you need.
【Application】 Cabinet Lithium Ion Phosphate(LiFePO4 )Battery Storage System can be used in most applications for Home energy storage,security and Safety,UPS,Telecommunication system,solar and wind energy system,emergency equipment,Power Station,Data center backup power.
